Product Description
Structurix D5:
Very fine grain film with high contrast. Excellent for visualization of discontinuities. This film is intended for use with lead screens, using either X-ray or gamma rays.
- Welding
- Castings
- Shipbuilding
- Aerospace and aircraft industry
- Multiple film techniques
| DESCRIPTION | PRODUCT CODE | SIZE | SHEETS / PKG | PKG / CASE |
|---|---|---|---|---|
| D5 BLR | 4PTO7 | 70mm X 1000′ | Roll | 3 |
| D5 BLR | 3EZJQ | 90mm X 1000′ | Roll | 2 |
| D5 BLR | 3RB66 | 70mm X 550′ | Roll | 3 |
| D5 ETE DW | 29J2F | 14 X 17″ | 100 | 1 |
| D5 NIF | 29LXF | 5 X 7″ | 100 | 5 |
| D5 NIF | 29MA7 | 4.5 X 10″ | 100 | 5 |
| D5 NIF | 3MOUR | 9 X 17″ | 100 | 5 |
| D5 NIF | 3TVQ2 | 3.5 X 8.5″ | 100 | 10 |
| D5 NIF | 3XK8Q | 3.5 X 10″ | 100 | 10 |
| D5 NIF | E7JJ6 | 3.5 X 17″ | 100 | 10 |
| D5 NIF | E7JK8 | 4.5 X 17″ | 100 | 5 |
| D5 NIF | LHVEH | 7 X 17″ | 100 | 5 |
| D5 NIF | LHVGM | 8 X 10″ | 100 | 5 |
| D5 NIF | LHVHO | 10 X 12″ | 100 | 5 |
| D5 NIF | LHVKS | 11 X 14″ | 100 | 5 |
| D5 NIF | LHVLU | 14 X 17″ | 100 | 5 |
| D5 Rollpac Pb | 293Q2 | 70mm X 90m | Roll | 2 |
| D5 Rollpac Pb | 293UB | 100mm X 90m | Roll | 2 |
| D5 Vacupac Pb | 3JOTY | 14 X 17″ | 100 | 1 |
| D5 Vacupac Pb | 29MKR | 10cm X 24cm | 100 | 6 |
